Size
Installation:	Pin Type
Dimensions(mm):	14.00*6.70

Electrical Characteristics
Frequency(Hz):	4.0K
Max current consumption(mA):	Max. 7.0@10Vp-p Square Wave. 4.0KHz
SPL(dB):	Min. 80dB@10cm/10Vp-p Square Wave. 4.0KHz
Electrostatic Capacity (pF):	8,500±30%@120Hz/1V
Tone:	Continuous

Others
Operation Temp.(℃):	-30~85
Storage Temp.(℃):	-40~+90
Material:	PBT+10% Glass (Black)
