Size
Installation:	Pin Type
Dimensions(mm):	24.00*6.70

Electrical Characteristics
Frequency(Hz):	6.0K
Max current consumption(mA):	Max. 8.0@10Vp-p Square Wave. 6.0KHz
SPL(dB):	Min. 90dB@10cm/10Vp-p Square Wave. 6.0KHz
Electrostatic Capacity (pF):	12,000±30%@1KHz/1V
Tone:	Continuous

Others
Operation Temp.(℃):	-30~85
Storage Temp.(℃):	-40~+95
Material:	ABS UL-94 1/16" HB High Heat (Black)
