| Size | |
| Installation: | Pin Type-Self Drive Type |
| Dimensions(mm): | 30.60*16.00 |
| Electrical Characteristics | |
| Frequency(Hz): | 3.25K±250 |
| Max current consumption(mA): | Max. 30.0@30cm/12VDC driven by RE46C100 |
| SPL(dB): | Min 105@30 cm/12VDC driven by RE46C100 |
| Tone: | Continuous |
| Others | |
| Operation Temp.(℃): | -40~85 |
| Storage Temp.(℃): | -40~+85 |
| Material: | PBT+15%Glass (BLACK) |
