RFQ |
 |
| Size | |
| Installation: | Hands-free |
| Dimensions(mm): | 16.00*36.50 |
| Electrical Characteristics | |
| Sensitivity(dB): | -43±3 |
| Impedance(Ω): | 2.0K |
| Rated Voltage(VDC): | 10 |
| Senvitivity Reduction(dB): | -3dB@f=1KHz, 1Pa, Vs=1.5V D.C. to 1.0V D.C. |
| Frequency(Hz): | 70~210,000 |
| Max current consumption(mA): | 0.5@Vs=1.5V D.C. RL=2.0KΩ |
| S/N Ratio(dBA): | 58 |
