| Size | |
| Shape: | Round Type |
| Dimensions(mm): | 36.00*18.70 |
| Electrical Characteristics | |
| Rated Input (W): | 1.50 |
| Max. Input (W): | 2.00 |
| Impedance(Ω): | 8±15%@2.0KHz 1.0V |
| FO (Hz): | 400±20%@1.0V |
| SPL(dB): | 97±3dB(1.0W/10cm)@AVG 0.8K, 1.0K, 1.2K, 1.5KHz |
| Frequency(Hz): | Fo---20K |
| Others | |
| Operation Temp.(℃): | -40~85 |
| Material: | ABS 777D |
